Description

Product Type: Document Scanner
Model: Avision AD370GN
Technology: Contact Image Sensor (CIS)
Light Source: LED
Document Feeding Mode: ADF

Resolution
Optical Resolution: 600 dpi
Output Resolution: Up to 1200 dpi

Scanning Speed
B/W @ 200dpi (A4): Simplex 70 ppm / Duplex 140 ipm
B/W @ 300dpi (A4): Simplex 70 ppm / Duplex 140 ipm
Colour @ 200dpi (A4): Simplex 70 ppm / Duplex 140 ipm
Colour @ 300dpi (A4): Simplex 70 ppm / Duplex 140 ipm

File Formats
BMP, PNG, GIF, JPEG, Single-Page PDF, Multi-Page PDF, Multi-TIFF, TIFF, RTF, TXT, OCR (iScan only), XPS, DOC, XLS, PPT, DOCS, XLSX, PPTX, HTML

Image Processing
Halftone: Dither, Error Diffusion
Grayscale Mode: 16-bit input / 8-bit output
Colour Mode: 48-bit input / 24-bit output

Memory
512MB SDRAM

Connectivity
Interface: USB 3.2 Gen1x1
Ethernet: RJ-45 (10/100/1000 Mb)
Network: RJ-45 (AD370N) / RJ-45 & Wi-Fi (AD370WN)
Wi-Fi Standard: IEEE 802.11 b/g/n

Media Handling
ADF Capacity: 100 sheets (A4, 80 g/m²)
ADF Minimum Size: 50 x 50 mm
ADF Maximum Size: 216 x 356 mm (Legal)
Paper Weight: 27–413 g/m²
Card Thickness: Up to 1.25 mm (embossed cards supported)

Long Paper Mode
Up to 240 in. (6096 mm) @ 200 dpi duplex
Up to 218 in. (5540 mm) @ 300 dpi duplex
Up to 59 in. (1500 mm) @ 600 dpi duplex

Performance
Recommended Daily Volume: Up to 15,000 pages
Ultrasonic Multi-feed Detection: Yes

Power Consumption
Operation: < 35W
Ready: < 9W
Sleep: < 2.15W
Off: < 0.2W

Acoustic Noise
Operation: < 52 dB
Ready: < 25 dB

Dimensions (W x D x H)
Maximum: 316 x 680 x 239 mm
Minimum: 316 x 191 x 168 mm

Weight
4.7 kg

Operating System Support
Windows 7, 8, 10, 11

Bundled Software
TWAIN Driver, ISIS Driver, Button Manager, PaperPort, AVScan, WIA Driver, WorldCard Team
